The R1/R2 Well Water System
The Well Water range of light industrial, commercial
and domestic harvesting systems treats the rainwater from your roof area (up
to 150mē) through a Micron Filter to DIN Standards. No particle larger than
0.28mm will enter the Well Water System. Over 90% of the rainwater is filtered and collected by our
system.
The Well Water system has an integral overflow system fitted with a non return valve to prevent surging
from the main drains, along with a water trap to stop smells and odour from overflow drains tainting the
rainwater in the Water Well System.
The patented filter system can be installed either above or below ground as with all Well Water components
the filter carries a guarantee.
In addition to the high performance Jung submersible pump the Well Water system
incorporates the Easy Press controller. This will operate the pump immediately
when the valve or tap in the pipe system is opened and stops the Jung Pump immediately
when the valve or tap is closed, or if the pump runs dry. The controller can
operate up to 15m away from the Jung Pump.
No programming is required for the
Easy Press controller. The R1 is designed for above or below ground installation.
The storage vessels for the Well Water Systems are manufactured from either HDPE
(high density polyethylene) or Resin Transfer Moulded Glass & Resin.
The R2 Well Water System is designed to supply internal appliances as well as
the outdoor uses. Rainwater can be used for toilet flushing and washing machines.
The
R2 system incorporates vortex filters solenoids and pump control units as well
as the many design features mentioned above for the R1 Well Water System. The
R2 can harvest rainwater from larger roof areas greater than 150mē. The R2
system is designed for below ground installation.
| Product Codes |
| The R1 Well Water System for Outdoor Application |
Product Range |
Dia mm |
Height mm |
Capacity Ltrs |
R1W1 |
1260 |
1500 |
1450 |
R1W2 |
1260 |
1600 |
1800 |
R1W3 |
1260 |
200 |
2150 |
R1W4 |
1260 |
1900 |
3400 |
R1W5 |
2300 |
2300 |
6000 |
|
| Product Codes |
| The R2 Well Water System for Indoor and Outdoor
Application |
Product Range |
Dia mm |
Height mm |
Capacity Ltrs |
R2W1 |
1260 |
1500 |
1450 |
R2W2 |
1260 |
1600 |
1800 |
R2W3 |
1260 |
200 |
2150 |
R2W4 |
1260 |
1900 |
3400 |
R2W5 |
2300 |
2300 |
6000 |
|
|
|
|
|
